The production line designed with advanced technology is mainly for producing large-diameter hollow wall winding pipe. The HDPE Hollow Wall Winding Pipe production line has a unique shape structure. So it has high ring stiffness, high impact strength and has the characteristics of light quality, easy construction, easy installation, resistance to external pressure and so on. The life span of the pipe is more than 50 years. It is the replacement product of cement pipe, cast iron pipe, and ceramic pipe. It has a wide application prospect and market potential.
Model of Kruto large-diameter hollow wall winding pipe production line
Model | Pipe Diameter Range (mm) | Extruder Model | Speed of Forming System (m/h) | Max.Output (kg/h) | Total Installed Power (kw) | Overall Dimension (m) |
KCRG-1200 | 400-1200 | KSJ-65(50)×30 | 1-12 | 320 | 230 | 26×18×5 |
KCRG-1600 | 800-1600 | KSJ-80(50)×30 | 1-6 | 500 | 310 | 27×18×5 |
KCRG-2200 | 1000-2200 | KSJ-90(65)×30 | 0.5-5 | 650 | 380 | 28×19×5 |
KCRG-3000 | 1600-3000 | KSJ-90(65)×30 | 0.3-3 | 800 | 390 | 48×26×6 |
